The supported Windows Operating System is Windows 10 64-bit. The Diamond Base and Service Pack (SP) executables contains all of the design tools and features for you to use Lattice FPGAs from design entry to bitstream download. Please see FAQ 6881 for further instructions. License: determine which license type you need, then request it on our licensing page via the button below.Īs part of Lattice on-going efforts for best-in-class security, Lattice has upgraded the IP and webserver URLs referenced by the Diamond software.Install: follow the installation guide, found in Documents section below.
Download Software Below - Windows / Linux.
Graphical environment timing and power analysis.Design exploration with multiple implementations and optimization strategies within a single project.Complete GUI based FPGA design and verification environment.
Optimized for Lattice Devices – Lattice Diamond offers an optimized and tailored design and verification environment for Lattice FPGAs featuring extensive constraints, advanced optimization, accurate analysis, extensive verification, and fast iterations. Lattice Diamond employs familiar easy to use tools and methodologies that make common tasks easier. Lattice Diamond allows for easy design exploration.Įasy to Use Powerful Tools – Adapting to a new tool is often difficult. Easy Design Exploration – Finding the best solutions often requires evaluating multiple solutions.
